Elcometer 480 Glossmeters
$3,158.10 – $6,494.40
The Elcometer 480 Glossmeter range are easy to use glossmeters which combine high accuracy, repeatability and reproducibility with functionality making them the most advanced gloss meters on the market today.
Combining easy to use, multi-lingual menu structures with exceptional repeatability, reproducibility & accuracy, the Elcometer 480 gloss meter provides users with best in class hand held gloss measurement.
Using state of the art design and manufacturing techniques, the Elcometer 480 glossmeter provides world leading features and functionality – reliably measuring & recording Gloss, % Reflectance & Haze on any material, including paint, plastic, ceramic or metal.
The Elcometer 480 gloss meter rapid LED technology accurately measures up to 3 gloss angles at the same time at a rate of 10 readings per second. Gloss measurements can be instantly transferred from the glossmeter to PC, iPhone, Android™ or other mobile devices via USB or Bluetooth®
elcometer 480 Gloss Meter data sheet
Key features of the Elcometer 480 Glossmeter include:
- Small, robust & ergonomic
- 3 – 10 readings per second
- Repeatable, reproducible & accurate
- Multiple angles; 20°, 60°, 85°
- 40,000 reading memory in up to 2,500 batches
- Date and time stamped readings
- USB & Bluetooth® data output
- PC, iPhone or Android™ compatible
- Automatic gauge & tile diagnostics
- Auto calibration tile recognition via RFID*
- 40 user definable limit standards
- Standard, auto repeat and scan modes
- Differential mode with pass/fail
- Display readings, statistics, graphs & batch review
Accessories
T48024798-LC Low Gloss Calibration Tile Nominal Value: 22GU at 60° ●
T48024798-MDC Mid Gloss Calibration Tile Nominal Value: 55GU at 60° ●
T48024798-HC High Gloss Calibration Tile* Nominal Value: 97GU at 60° ●
T48024798-MRC Mirror Gloss Calibration Tile Nominal Value: 1900GU at 20° ●
T48024798-SH Soft Material Specimen Holder, complete with 3 sample trays
T48025004 Soft Material Sample Trays (x3)
T99923535 Gloss Tile Cleaning Cloth
T99925002 USB Cable
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Options | J480B-6 Elcometer 480 Model B 60° Glossmeter, J480T-6 Elcometer 480 Model T 60° Glossmeter, J480T-26 Elcometer 480 Model T 20/60° Glossmeter, J480T-268 Elcometer 480 Model T 20/60/85° Glossmeter |
